Pipe DN 150 ECOPUR HYDROTIGHT

Version: HYDROTIGHT push-in socket joint | TYTON seal | installation length 6 m
BLS push-in socket connection | TYTON seal | length 6 m
Standards: EN 545 | EN 15 655 | Factory standard
Material: Ductile cast iron | Outer coating polyurethane (PUR) | EPDM gasket
Inner lining: Polyurethane (PUR) | EPDM seal

Characteristics

Outer sleeve diameter 239 mm
Outer tube shaft diameter 170 mm
Inside diameter 152.6 mm
Height 1 m
Gross weight 28.2 kg
Casing duktiles Gusseises
Max. permissible operating pressure max. PFA 100 (Ausführung BLS)
Max. permissible operating pressure 25 PFA bis DN400

Pipe DN 150 ECOPUR HYDROTIGHT
DUKTUS VONROLL ECOPUR HYDROTIGHT, DN 80 - 400- Drinking water

All prices excl.

CHF 0.00
Sustainability 🍃

At VONROLL HYDRO, respectful handling of resources has always been lived and legal regulations regarding the environment are complied with or even exceeded. With the further development of the environmental management system and the associated certification according to ISO 14001, the company underlines its environmental commitment. It is committed to providing the necessary means and structures to manufacture and distribute ecologically optimal products and equipment in the most environmentally friendly way possible. However, use and disposal should also have no negative impact on the environment.

We have reduced the use of natural resources and also reduced the amount of waste that cannot be put to good use. Reusable parts and materials are used for our products. These can be reprocessed, recycled, or reused in a completely different way.
